Bezel-free MonitorBezel-free Monitor

TM4010R

Secondary Touch Screen Monitor


A secondary monitor with a bezel-free display and a PCAP touch, the TM4010R supports a resolution of 1024*768. This secondary monitor also comes with different viewing angles and VGA display interface.

Add to Compare

Key Features


  • 9.7-inch TFT PCAP Touch Screen
  • Viewing Angles: 60/70/70/70 (U/D/L/R)
  • VGA Display Interface
  • 12V Power Supply from VGA Terminal
Category:

Additional information

System Configuration
Power Supply

12V from Posiflex terminal VGA port
Display & Touch
LCD Display

9.7" TFT LCD

Resolution

1024 x 768

Touch Function

Bezel-Free PCAP touch
Physical Characteristics
Viewing Angle

60 / 70 / 70 / 70 degree (U / D / L / R)
Touch
Interface

USB
General Specification
Display Interface

VGA
Others
Active Area

196.61 (H) x 147.46 (V)

Pixel Arrangement

RGB Vertical Stripe

Pixel Pitch

0.192 (H) x 0.192 (V)
Display
Brightness

350 cd/m2

Contrast Ratio

500 : 1

Response Time

20 ms (Raising + Falling)
E-Brochures
Brochure for TM-4010 R (EN) Download
User Manual
User Manual for TM/LM-401X (EN) Download
